Product Model T-0150IU(15") T-0170IU(17") T-0190IU(19")
Resolution 1024 x 768@60Hz 1280 x 1024@60Hz 1280 x 1024@60Hz
View Area 304.8(W) x 228.7(H)mm 339.8(W) x 272.5(H)mm 378.3(W) x 303.0(H)mm
Pixel Pitch 0.297(H) x 0.297(V)mm 0.264(H) x 0.264(V)mm 0.098(H) x 0.294(V)mm
Color Depth 16.7M colors 16.7M colors 16.7M colors
Contrast Ratio(Typ.) 800 : 1 800 : 1 800 : 1
Luminance 250 cd/(typ) 300 cd/(typ) 300 cd/(typ)
Response Time 8ms 5ms 5ms
Viewing Angle 140(H) x 140(V) 160(H) x 160(V) 160(H) x 160(V)
Detection Form   Infrared rays interception detection form
Report Rate   Averge. 50 time/sec
Operating Systems   Windows 98/ME/2000/XP/VISTA
Touch Interface   USB 1.1/2.0
Supply Voltage   12[V]DC
OSD Language   English, Germany, French, Spanish, Korean
Storage Temperature -10 ~60 -10 ~60 -10 ~60
Operation Temperature 0 ~ 40 0 ~ 40 0 ~ 40
Power Consumption 20W 21W 22W
Weight 6.5kg 7kg 7.5kg
Accessory Driver CD, DC Adaptor, Power Code, RGB Cable, Touch Cable (DVI Cable Option)
Warranty 3 Years
